CAT50 ER32 8.00" Dual Contact ER Collet Chuck - GS Tooling 521458

Name: CAT50 ER32 8.00" Dual Contact ER Collet Chuck - GS Tooling 521458
Brand: Cutting Tool Pickers
SKU: 3000-521458
Price: 481.0 CAD
Availability: InStock

SKU 3000-521458

$481.00 - $481.00

$481.00

$481.00 - $481.00

$481.00

• Minimum Collet Capacity (Decimal Inch) : 0.078
• Maximum Collet Capacity (Decimal Inch) : 0.787
• Balanced to (RPM) : 25000
• Collet Nut Diameter (Decimal Inch) : 1.97
• Seat Depth (Decimal Inch) : 1.34
• Tightening Torque (Nm) : 169.5
• Collet System : ER
• Collet Series: ER32
• Shank Type: Taper Shank
• Taper Size: CAT50
• Projection (Decimal Inch): 8
• Improves rigidity and reduces vibration allowing for increased feed rates and increased tool life
• DIN coolant option - standard
• All Ground Body

06/24
521458
