CAT50 ER32 6.00" Dual Contact ER Collet Chuck - GS Tooling 521456

Name: CAT50 ER32 6.00" Dual Contact ER Collet Chuck - GS Tooling 521456
Brand: Cutting Tool Pickers
SKU: 3000-521456
Price: 499.95 CAD
Availability: InStock

SKU 3000-521456

$499.95 - $499.95

$499.95

$499.95 - $499.95

$499.95

• Minimum Collet Capacity (Decimal Inch) : 0.078
• Maximum Collet Capacity (Decimal Inch) : 0.787
• Balanced to (RPM) : 25000
• Collet Nut Diameter (Decimal Inch) : 1.97
• Seat Depth (Decimal Inch) : 1.34
• Tightening Torque (Nm) : 169.5
• Collet System : ER
• Collet Series: ER32
• Shank Type: Taper Shank
• Taper Size: CAT50
• Projection (Decimal Inch): 6
• Improves rigidity and reduces vibration allowing for increased feed rates and increased tool life
• DIN coolant option - standard
• All Ground Body

07/23
521456
