CAT50 ER16 6.00" Dual Contact ER Collet Chuck - GS Tooling 521434

Name: CAT50 ER16 6.00" Dual Contact ER Collet Chuck - GS Tooling 521434
Brand: Cutting Tool Pickers
SKU: 3000-521434
Price: 439.0 CAD
Availability: InStock

SKU 3000-521434

$439.00 - $439.00

$439.00

$439.00 - $439.00

$439.00

• Minimum Collet Capacity (Decimal Inch) : 0.019
• Maximum Collet Capacity (Decimal Inch) : 0.406
• Balanced to (RPM) : 25000
• Collet Nut Diameter (Decimal Inch) : 1.26
• Seat Depth (Decimal Inch) : 0.87
• Tightening Torque (Nm) : 56.9
• Collet System : ER
• Collet Series: ER16
• Shank Type: Taper Shank
• Taper Size: CAT50
• Projection (Decimal Inch): 6
• Improves rigidity and reduces vibration allowing for increased feed rates and increased tool life
• DIN coolant option - standard
• All Ground Body

07/23
521434
