CAT40 ER40 2.50" Dual Contact Collet Chuck - GS Tooling 521666

Name: CAT40 ER40 2.50" Dual Contact Collet Chuck - GS Tooling 521666
Brand: Cutting Tool Pickers
SKU: 3000-521666
Price: 313.0 CAD
Availability: InStock

SKU 3000-521666

$313.00 - $313.00

$313.00

$313.00 - $313.00

$313.00

• Minimum Collet Capacity (Decimal Inch): 0.118"
• Maximum Collet Capacity (Decimal Inch): 1.023"
• Balanced to (RPM): 30000
• TIR (Decimal Inch): 0.0003"
• Coolant Type: DIN
• Collet Nut Diameter (Decimal Inch): 2.48"
• Collet System: ER
• Collet Series: ER40
• Shank Type: Taper
• Taper Size: CAT40
• Projection (Decimal Inch): 2.50"
• Through Coolant: Yes

06/24
521666
Sowa Tool
